Dispersion Prisms

The prism can not only turn the light at a specific angle to offset the light, but also adjust the direction of the image. The shape and function of the prism can be determined according to its intera..

Dispersion Prisms

产品说明

The prism can not only turn the light at a specific angle to offset the light, but also adjust the direction of the image. The shape and function of the prism can be determined according to its interaction with light. When light is incident on a prism, it will be reflected on one or more surfaces before it is emitted, or it will be refracted as it passes through the substrate. 100 Optical provides various forms of prisms, including but not limited to Triangular prism, Penta prism, Dove prism, Powell prism, Roof prism, Corner Cube , etc

Dimension Tolerance	±0.2mm,+0.0，-0.2mm
Flatness	λ/4@632.8nm
Surface Quality	60-40 scratch and dig
Angle Tolerance	<3 arc minutes or High Precision
Bevel	0.2 to 0.5mm
Coating	According to customer requirements
