Rochon Polarizer

Rochon Polarizer Rochon Polarizer is the earliest polarizer, which is made of two birefringence material prisms that are cemented together. This type polarizer separates incident beam into ordinary ra..

Rochon Polarizer

产品说明

Rochon Polarizer Rochon Polarizer is the earliest polarizer, which is made of two birefringence material prisms that are cemented together. This type polarizer separates incident beam into ordinary ray and extra-ordinary ray like Wollaston Polarizer, but the extra-ordinary ray is straight transmitted through, while ordinary is transmitted with a deviation angle.

Material: MgF2,α-BBO, Calcite ,YVO4 or Quartz
Wavelength Range: MgF2:130-4000nm; α-BBO:190-3500nm; YVO4:400-4000nm; Quartz:200-2300nm
Extinction Ratio： MgF2:＜5×10-6; α-BBO:＜5×10-6; YVO4 ：＜5×10-6;
Quartz:＜5×10-5
Surface Quality： 10/20
Beam Deviation: ＜3 arc minutes
Wavefornt Distortion: λ/4@633nm
Damage Threshold： ＞500MW/cm2
Coating： Single Layer MgF2

Features:

Optical Cemented
High Polarization Purity
Suitable for Low or High Power Application
